Swift Charging: LiFePO4 technology allows for rapid charging, minimizing downtime and ensuring your devices or vehicles are quickly ready for use. Quick charging also supports regenerative braking in electric vehicles.
High Discharge Rate: Our lifepo4 battery cell can deliver high discharge currents, making them suitable for applications requiring bursts of power, such as electric vehicles and power tools.
PRODUCT SPECIFICATIONS:
ELECTRICAL SPECIFICATIONS
| VOLTAGE: |
3.2V |
| NOMINAL CAPACITY: |
200Ah |
| NOMINAL ENERGY: |
640Wh |
| CYCLE LIFE: |
≥4000 times |
MECHANICAL SPECIFICATIONS
| DIMENSION(LXWXH): |
54*173*207mm |
| WEIGHT: |
3.9Kg |
| CELL TYPE/CHEMISTRY: |
Cylindrical LiFePO4 |
| TERMINALS: |
standard Screw terminals |
CHARGE&DISCHARGE SPECIFICATIONS
| CHARGE METHOD: |
CCCV |
| CHARGE VOLTAGE: |
2.5-3.65V |
| MAX. CHARGE CURRENT: |
200A |
| END OF DISCHARGE VOLTAGE: |
2.5V |
| DISCHARGE CURRENT CONTINUOUS: |
200A |
TEMPERATURE SPECIFICATIONS
| CHARGE TEMPERATURE: |
0℃~45℃ |
| DISCHARGE TEMPERATURE: |
-20℃~60℃ |
| STORAGE TEMPERATURE: |
15～+35℃ |
COMPLIANCE SPECIFICATIONS:
| CERTIFICATION: |
RoHs, CE |
| SHIPPING METHOD: |
Expressage, by Sea, by Railway, by Air |
COMPLIANCE SPECIFICATIONS:
| THE BATTERY CAN BE IN SERIES IN 4 OR IN PARALLEL IN 4, BUT NOT AT THE SAME TIME. |
